Schema documentation for component diggs:AbstractSamplingFeature

Abstract head of the substitution group for sampling features. A sampling feature is a physical object or location through which properties of an investigation target are observed or measured, or through which some type of activity is performed. It defines the dimensionality, extent and local spatial reference system of the zones where observations or activities take place.

<diggs:AbstractSamplingFeature gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:investigationTarget>{0,unbounded}</diggs:investigationTarget>
  <diggs:projectRef xlink:href="" identifierRef="" nilReason="" owns="false">{1,unbounded}</diggs:projectRef>
  <diggs:originalProjectRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:originalProjectRef>
  <diggs:associatedProjectRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:associatedProjectRef>
  <diggs:samplingFeatureGroupRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:samplingFeatureGroupRef>
  <diggs:programRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:programRef>
  <diggs:currentDesign xlink:href="" nilReason="" owns="false">{0,1}</diggs:currentDesign>
  <diggs:previousDesign xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:previousDesign>
  <diggs:programSpecificationRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:programSpecificationRef>
  <diggs:realizesGridIndex dimension="2">{0,1}</diggs:realizesGridIndex>
  <diggs:environment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:environment>
  <diggs:otherSamplingFeatureProperty>{0,unbounded}</diggs:otherSamplingFeatureProperty>
  <diggs:locality>{0,1}</diggs:locality>
  <diggs:referencePoint owns="false" xlink:href="" nilReason="">{1,1}</diggs:referencePoint>
  <diggs:localCoordinates>{0,1}</diggs:localCoordinates>
</diggs:AbstractSamplingFeature>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="true" name="AbstractSamplingFeature" type="diggs:AbstractSamplingFeatureType"> <annotation> <documentation>Abstract head of the substitution group for sampling features. A sampling feature is a physical object or location through which properties of an investigation target are observed or measured, or through which some type of activity is performed. It defines the dimensionality, extent and local spatial reference system of the zones where observations or activities take place.</documentation> </annotation> </element>
