Schema documentation for component diggs:Station

<diggs:Station gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:investigationTarget>{0,unbounded}</diggs:investigationTarget>
  <diggs:projectRef xlink:href="" identifierRef="" nilReason="" owns="false">{1,unbounded}</diggs:projectRef>
  <diggs:originalProjectRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:originalProjectRef>
  <diggs:associatedProjectRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:associatedProjectRef>
  <diggs:samplingFeatureGroupRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:samplingFeatureGroupRef>
  <diggs:programRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:programRef>
  <diggs:currentDesign xlink:href="" nilReason="" owns="false">{0,1}</diggs:currentDesign>
  <diggs:previousDesign xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:previousDesign>
  <diggs:programSpecificationRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:programSpecificationRef>
  <diggs:realizesGridIndex dimension="2">{0,1}</diggs:realizesGridIndex>
  <diggs:environment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:environment>
  <diggs:otherSamplingFeatureProperty>{0,unbounded}</diggs:otherSamplingFeatureProperty>
  <diggs:locality>{0,1}</diggs:locality>
  <diggs:referencePoint owns="false" xlink:href="" nilReason="">{1,1}</diggs:referencePoint>
  <diggs:localCoordinates>{0,1}</diggs:localCoordinates>
  <diggs:whenOccupied>{0,1}</diggs:whenOccupied>
  <diggs:type codeSpace="">{0,1}</diggs:type>
</diggs:Station>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="false" name="Station" substitutionGroup="diggs:AbstractPointSamplingFeature" type="diggs:StationType"> <annotation> <documentation>A sampling feature that is a point in or on the earth's surface where observations or tests are performed, where samples are collected, or where monitoring devices are installed.</documentation> </annotation> </element>
