Schema documentation for component diggs:PlateLoadTest

A plate-bearing load test on the head of a single deep foundation element, per ASTM D1194 (withdrawn in 2003, still in practical use), ASTM D1195/D1196 or DIN 18134. It has no fields of its own; diggs:AbstractPlateBearingTestProcedureType carries everything it needs. It is distinguished from diggs:ZoneLoadTest by what Test/samplingFeatureRef cites: a single diggs:RIColumn here, a diggs:LoadTransferPlatform there.

<diggs:PlateLoadTest gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:testProcedureMethod xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureMethod>
  <diggs:testProcedureEquipment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureEquipment>
  <diggs:testingEnvironment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testingEnvironment>
  <diggs:otherTestProperty>{0,unbounded}</diggs:otherTestProperty>
  <diggs:testEvent>{0,unbounded}</diggs:testEvent>
  <diggs:referenceSystem>{0,1}</diggs:referenceSystem>
  <diggs:maxTestLoad howDetermined="" qualifier="" uom="">{0,1}</diggs:maxTestLoad>
  <diggs:increment>{0,unbounded}</diggs:increment>
  <diggs:maxTestStress howDetermined="" qualifier="" uom="">{0,1}</diggs:maxTestStress>
  <diggs:deadLoad howDetermined="" qualifier="" uom="">{0,1}</diggs:deadLoad>
  <diggs:plateDiameter howDetermined="" qualifier="" uom="">{0,1}</diggs:plateDiameter>
  <diggs:plateWidth howDetermined="" qualifier="" uom="">{0,1}</diggs:plateWidth>
  <diggs:plateLength howDetermined="" qualifier="" uom="">{0,1}</diggs:plateLength>
  <diggs:plateArea howDetermined="" qualifier="" uom="">{0,1}</diggs:plateArea>
  <diggs:plateStiffness>{0,1}</diggs:plateStiffness>
  <diggs:seatingLoad howDetermined="" qualifier="" uom="">{0,1}</diggs:seatingLoad>
  <diggs:bearingLevel owns="false" xlink:href="" nilReason="">{0,1}</diggs:bearingLevel>
  <diggs:loadingProcedure>{0,1}</diggs:loadingProcedure>
  <diggs:seatingStress howDetermined="" qualifier="" uom="">{0,1}</diggs:seatingStress>
  <diggs:beddingMaterial>{0,1}</diggs:beddingMaterial>
</diggs:PlateLoadTest>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="PlateLoadTest" type="diggs:PlateLoadTestType" abstract="false" substitutionGroup="diggs:AbstractPlateBearingTestProcedure"> <annotation> <documentation>A plate-bearing load test on the head of a single deep foundation element, per ASTM D1194 (withdrawn in 2003, still in practical use), ASTM D1195/D1196 or DIN 18134. It has no fields of its own; diggs:AbstractPlateBearingTestProcedureType carries everything it needs. It is distinguished from diggs:ZoneLoadTest by what Test/samplingFeatureRef cites: a single diggs:RIColumn here, a diggs:LoadTransferPlatform there.</documentation> </annotation> </element>
