Schema documentation for component diggs:TrialPit

A relatively shallow excavation into the earth's surface, dug either manually or by a mechanical excavator. Samples,observations and tests in the trial pit are referenced in a linear referencing system only (1D). This is a legacy sampling feature to support AGS trial pit constructs. The TrenchWall sampling feature should be used to represent more detail on walls of pits or trenches in 2D.

<diggs:TrialPit gml:id="" xml:lang="" xmlns:diggs="http://diggsml.org/schema-dev" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:investigationTarget>{1,unbounded}</diggs:investigationTarget>
  <diggs:projectRef xlink:actuate="" xlink:arcrole="" xlink:href="" identifierRef="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{1,1}</diggs:projectRef>
  <diggs:originalProjectRef xlink:actuate="" xlink:arcrole="" xlink:href="" identifierRef="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</diggs:originalProjectRef>
  <diggs:associatedProjectRef xlink:actuate="" xlink:arcrole="" xlink:href="" identifierRef="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:associatedProjectRef>
  <diggs:programRef xlink:actuate="" xlink:arcrole="" xlink:href="" identifierRef="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</diggs:programRef>
  <diggs:environment>{0,unbounded}</diggs:environment>
  <diggs:otherSamplingFeatureProperty>{0,unbounded}</diggs:otherSamplingFeatureProperty>
  <diggs:locality>{0,1}</diggs:locality>
  <diggs:referencePoint xlink:actuate="" xlink:role="" xlink:arcrole="" xlink:show="" xlink:title="" xlink:href="" xlink:type="simple" nilReason="" owns="false">{1,1}</diggs:referencePoint>
  <diggs:localCoordinates>{0,1}</diggs:localCoordinates>
  <diggs:centerLine xlink:actuate="" xlink:role="" xlink:arcrole="" xlink:show="" xlink:title="" xlink:href="" xlink:type="simple" nilReason="" owns="false">{1,unbounded}</diggs:centerLine>
  <diggs:linearReferencing>{0,unbounded}</diggs:linearReferencing>
  <diggs:plunge uom="">{0,1}</diggs:plunge>
  <diggs:bearing refAzimuth="" uom="">{0,1}</diggs:bearing>
  <diggs:whenConstructed>{0,1}</diggs:whenConstructed>
  <diggs:totalMeasuredDepth uom="">{0,1}</diggs:totalMeasuredDepth>
  <diggs:pitLength uom="">{0,1}</diggs:pitLength>
  <diggs:pitWidth uom="">{0,1}</diggs:pitWidth>
  <diggs:shoring xml:lang="">{0,1}</diggs:shoring>
  <diggs:trialPitPurpose codeSpace="">{0,1}</diggs:trialPitPurpose>
  <diggs:backfill>{0,1}</diggs:backfill>
  <diggs:constructionMethod>{0,unbounded}</diggs:constructionMethod>
  <diggs:constructionEvent>{0,unbounded}</diggs:constructionEvent>
</diggs:TrialPit>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<div> <h3>lang (as an attribute name)</h3> <p>denotes an attribute whose value is a language code for the natural language of the content of any element; its value is inherited. This name is reserved by virtue of its definition in the XML specification.</p> </div> <div> <h4>Notes</h4> <p>Attempting to install the relevant ISO 2- and 3-letter codes as the enumerated possible values is probably never going to be a realistic possibility.</p> <p>See BCP 47 at <a href="http://www.rfc-editor.org/rfc/bcp/bcp47.txt">http://www.rfc-editor.org/rfc/bcp/bcp47.txt</a>and the IANA language subtag registry at <a href="http://www.iana.org/assignments/language-subtag-registry">http://www.iana.org/assignments/language-subtag-registry</a>for further information.</p> <p>The union allows for the 'un-declaration' of xml:lang with the empty string.</p> </div>

<element name="TrialPit" substitutionGroup="diggs:AbstractLinearSamplingFeature" type="diggs:TrialPitType"> <annotation> <documentation>A relatively shallow excavation into the earth's surface, dug either manually or by a mechanical excavator. Samples,observations and tests in the trial pit are referenced in a linear referencing system only (1D). This is a legacy sampling feature to support AGS trial pit constructs. The TrenchWall sampling feature should be used to represent more detail on walls of pits or trenches in 2D.</documentation> </annotation> </element>
