Schema documentation for component diggs:Sample

<diggs:Sample gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:projectRef xlink:href="" identifierRef="" nilReason="" owns="false">{1,1}</diggs:projectRef>
  <diggs:samplingActivityRef xlink:href="" identifierRef="" nilReason="" owns="false">{1,1}</diggs:samplingActivityRef>
  <diggs:programRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:programRef>
  <diggs:programSpecificationRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:programSpecificationRef>
  <diggs:sampleProducedRef xlink:href="" nilReason="" owns="false">{1,1}</diggs:sampleProducedRef>
  <diggs:sampleGroupRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:sampleGroupRef>
  <diggs:relativeReferencingSystem>{0,1}</diggs:relativeReferencingSystem>
  <diggs:relativeReferenceSystemOrigin>{0,1}</diggs:relativeReferenceSystemOrigin>
  <diggs:classification>{0,1}</diggs:classification>
  <diggs:type codeSpace="">{0,1}</diggs:type>
  <diggs:condition codeSpace="">{0,1}</diggs:condition>
  <diggs:qualityClass codeSpace="">{0,1}</diggs:qualityClass>
  <diggs:extrusionMethod codeSpace="">{0,1}</diggs:extrusionMethod>
  <diggs:initialContainer xlink:href="" nilReason="" owns="false">{0,1}</diggs:initialContainer>
  <diggs:purpose>{0,1}</diggs:purpose>
  <diggs:sampleWeight howDetermined="" qualifier="" uom="">{0,1}</diggs:sampleWeight>
  <diggs:sampleMass howDetermined="" qualifier="" uom="">{0,1}</diggs:sampleMass>
  <diggs:sampleVolume howDetermined="" qualifier="" uom="">{0,1}</diggs:sampleVolume>
  <diggs:sampleDimensions>{0,1}</diggs:sampleDimensions>
  <diggs:sampleMatrix codeSpace="">{0,1}</diggs:sampleMatrix>
  <diggs:initialPreservationMethod>{0,1}</diggs:initialPreservationMethod>
  <diggs:chainOfCustodyEvent>{0,unbounded}</diggs:chainOfCustodyEvent>
  <diggs:otherSampleProperty>{0,unbounded}</diggs:otherSampleProperty>
  <diggs:coreDistkurbance codeSpace="">{1,1}</diggs:coreDistkurbance>
  <diggs:coreDisturbance codeSpace="">{1,1}</diggs:coreDisturbance>
</diggs:Sample>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="false" name="Sample" substitutionGroup="diggs:AbstractSample" type="diggs:SampleType"> <annotation> <documentation>A material sample, solid, fluid or gas, obtained as a result of a sampling activity for observation or testing.</documentation> </annotation> </element>
