Schema documentation for component diggs:ConstructionActivitySpecification

A program specification governing how a construction activity is carried out, as distinct from what the finished feature must be: the method to follow, the equipment to use and the telemetry the work must record. Requirements the activity must meet, such as a termination or refusal rule, are criteria that name this specification through partOfSpecificationRef, and the activity cites the specification through programSpecificationRef.

<diggs:ConstructionActivitySpecification gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:basedOnRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:basedOnRef>
  <diggs:basisRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:basisRef>
  <diggs:appliesToZone xlink:href="" nilReason="" owns="false">{0,1}</diggs:appliesToZone>
  <diggs:appliesToFeatureType codeSpace="">{0,1}</diggs:appliesToFeatureType>
  <diggs:constructionMethod xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:constructionMethod>
  <diggs:recordingParameter codeSpace="">{0,unbounded}</diggs:recordingParameter>
  <diggs:requiredEquipment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:requiredEquipment>
</diggs:ConstructionActivitySpecification>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="ConstructionActivitySpecification" type="diggs:ConstructionActivitySpecificationType" substitutionGroup="diggs:AbstractProgramSpecification"> <annotation> <documentation>A program specification governing how a construction activity is carried out, as distinct from what the finished feature must be: the method to follow, the equipment to use and the telemetry the work must record. Requirements the activity must meet, such as a termination or refusal rule, are criteria that name this specification through partOfSpecificationRef, and the activity cites the specification through programSpecificationRef.</documentation> </annotation> </element>
