Schema documentation for component diggs:Project

A business activity that encompasses a collection of sampling features, activities, samples, observations and measurements, and is typically undertaken for a specific outcome such as a research publication, a design or a geotechnical construction (deep foundation, earthwork and so on). A project may occur at a physical location, in which case it can contain geometries.

<diggs:Project gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:referencePoint owns="false" xlink:href="" nilReason="">{0,1}</diggs:referencePoint>
  <diggs:linearExtent owns="false" xlink:href="" nilReason="">{0,unbounded}</diggs:linearExtent>
  <diggs:arealExtent owns="false" xlink:href="" nilReason="">{0,unbounded}</diggs:arealExtent>
  <diggs:projectDateTimeSpan>{0,1}</diggs:projectDateTimeSpan>
  <diggs:locality>{0,unbounded}</diggs:locality>
  <diggs:purpose codeSpace="">{0,1}</diggs:purpose>
  <diggs:projectEvent>{0,unbounded}</diggs:projectEvent>
  <diggs:contract>{0,unbounded}</diggs:contract>
  <diggs:otherProjectProperty>{0,unbounded}</diggs:otherProjectProperty>
  <diggs:projectGroupRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:projectGroupRef>
</diggs:Project>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="Project" type="diggs:ProjectType" substitutionGroup="diggs:AbstractProject" abstract="false"> <annotation> <documentation>A business activity that encompasses a collection of sampling features, activities, samples, observations and measurements, and is typically undertaken for a specific outcome such as a research publication, a design or a geotechnical construction (deep foundation, earthwork and so on). A project may occur at a physical location, in which case it can contain geometries.</documentation> </annotation> </element>

Showing:
