Schema documentation for component diggs:AbstractMaterialTestProcedure

Abstract head of the substitution group for material test procedures: procedures performed only on manufactured samples, for example those created by aggregating other samples or materials, where the sample has no location relevance. A material test procedure must reference or describe the samples or specimens on which the test is performed. Used for characterizing grout samples, and for other samples where the results relate to the sample only and not to a geographic feature of interest.

<diggs:AbstractMaterialTestProcedure gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:testProcedureMethod xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureMethod>
  <diggs:testProcedureEquipment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureEquipment>
  <diggs:testingEnvironment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testingEnvironment>
  <diggs:otherTestProperty>{0,unbounded}</diggs:otherTestProperty>
  <diggs:testEvent>{0,1}</diggs:testEvent>
  <diggs:sampleRef xlink:href="" identifierRef="" nilReason="" owns="false" percentage="">{1,unbounded}</diggs:sampleRef>
  <diggs:specimen xlink:href="" nilReason="" owns="false">{1,unbounded}</diggs:specimen>
</diggs:AbstractMaterialTestProcedure>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="true" name="AbstractMaterialTestProcedure" substitutionGroup="diggs:AbstractTestProcedure" type="diggs:AbstractMaterialTestProcedureType"> <annotation> <documentation>Abstract head of the substitution group for material test procedures: procedures performed only on manufactured samples, for example those created by aggregating other samples or materials, where the sample has no location relevance. A material test procedure must reference or describe the samples or specimens on which the test is performed. Used for characterizing grout samples, and for other samples where the results relate to the sample only and not to a geographic feature of interest.</documentation> </annotation> </element>
