Schema documentation for component diggs:MCVTest

A moisture condition value (MCV) test procedure. The MCV, determined from a moisture condition test, indicates how much compactive effort is needed to compact a soil sample at a particular moisture content. A captive weight is dropped a known distance onto a sample in a cylindrical mould and the compaction is measured; counting the blows needed for the required compaction gives the MCV of the soil at that moisture content.

<diggs:MCVTest gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:testProcedureMethod xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureMethod>
  <diggs:testProcedureEquipment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureEquipment>
  <diggs:testingEnvironment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testingEnvironment>
  <diggs:otherTestProperty>{0,unbounded}</diggs:otherTestProperty>
  <diggs:testEvent>{0,1}</diggs:testEvent>
  <diggs:specimen xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:specimen>
  <diggs:typeStabilizer codeSpace="">{0,1}</diggs:typeStabilizer>
  <diggs:amtStabilizer howDetermined="" qualifier="" uom="">{0,1}</diggs:amtStabilizer>
  <diggs:trial>{0,unbounded}</diggs:trial>
</diggs:MCVTest>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="MCVTest" type="diggs:MCVTestType" abstract="false" substitutionGroup="diggs:AbstractLaboratoryTestProcedure"> <annotation> <documentation>A moisture condition value (MCV) test procedure. The MCV, determined from a moisture condition test, indicates how much compactive effort is needed to compact a soil sample at a particular moisture content. A captive weight is dropped a known distance onto a sample in a cylindrical mould and the compaction is measured; counting the blows needed for the required compaction gives the MCV of the soil at that moisture content.</documentation> </annotation> </element>
