Schema documentation for component diggs:SamplingActivity

The action taken to obtain or produce material samples, even if it fails to produce one (for example a core run with no recovery). The activity type states whether the samples result from collection at a sampling feature, subsampling, aggregation of samples, or creation of a test or blank sample. Every sample refers to a sampling activity.

<diggs:SamplingActivity gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:investigationTarget>{0,unbounded}</diggs:investigationTarget>
  <diggs:projectRef xlink:href="" identifierRef="" nilReason="" owns="false">{1,unbounded}</diggs:projectRef>
  <diggs:programRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:programRef>
  <diggs:currentDesign xlink:href="" nilReason="" owns="false">{0,1}</diggs:currentDesign>
  <diggs:previousDesign xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:previousDesign>
  <diggs:programSpecificationRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:programSpecificationRef>
  <diggs:constructionActivityRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:constructionActivityRef>
  <diggs:samplingFeatureRef xlink:href="" identifierRef="" nilReason="" owns="false">{1,1}</diggs:samplingFeatureRef>
  <diggs:samplingLocation owns="false" xlink:href="" nilReason="">{1,1}</diggs:samplingLocation>
  <diggs:associatedProjectRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,unbounded}</diggs:associatedProjectRef>
  <diggs:originalProjectRef xlink:href="" identifierRef="" nilReason="" owns="false">{0,1}</diggs:originalProjectRef>
  <diggs:sourceSampleRef xlink:href="" identifierRef="" nilReason="" owns="false" percentage="">{0,unbounded}</diggs:sourceSampleRef>
  <diggs:activityType>{1,1}</diggs:activityType>
  <diggs:lengthLongestPortion howDetermined="" qualifier="" uom="">{0,1}</diggs:lengthLongestPortion>
  <diggs:purpose>{0,1}</diggs:purpose>
  <diggs:rockQualityDesignationLength howDetermined="" qualifier="" uom="">{0,1}</diggs:rockQualityDesignationLength>
  <diggs:samplingActivityRQD howDetermined="" qualifier="" uom="">{0,1}</diggs:samplingActivityRQD>
  <diggs:sampleProduced>{0,unbounded}</diggs:sampleProduced>
  <diggs:samplerInsertionMethod codeSpace="">{0,1}</diggs:samplerInsertionMethod>
  <diggs:samplingCategory codeSpace="">{0,1}</diggs:samplingCategory>
  <diggs:samplingDate>{0,1}</diggs:samplingDate>
  <diggs:samplingEnvironment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:samplingEnvironment>
  <diggs:samplingEquipment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:samplingEquipment>
  <diggs:samplingMethod xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:samplingMethod>
  <diggs:solidCoreRecoveryLength howDetermined="" qualifier="" uom="">{0,1}</diggs:solidCoreRecoveryLength>
  <diggs:totalSampleRecoveryLength howDetermined="" qualifier="" uom="">{0,1}</diggs:totalSampleRecoveryLength>
  <diggs:totalSampleRecovery howDetermined="" qualifier="" uom="">{0,1}</diggs:totalSampleRecovery>
  <diggs:mixingTime howDetermined="" qualifier="" uom="">{0,1}</diggs:mixingTime>
  <diggs:otherSamplingActivityProperty>{0,unbounded}</diggs:otherSamplingActivityProperty>
  <diggs:coringPushPressure howDetermined="" qualifier="" uom="">{0,1}</diggs:coringPushPressure>
  <diggs:coringPushPressureMin howDetermined="" qualifier="" uom="">{0,1}</diggs:coringPushPressureMin>
  <diggs:coringPushPressureMax howDetermined="" qualifier="" uom="">{0,1}</diggs:coringPushPressureMax>
</diggs:SamplingActivity>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="false" name="SamplingActivity" substitutionGroup="diggs:AbstractSamplingActivity" type="diggs:SamplingActivityType"> <annotation> <documentation>The action taken to obtain or produce material samples, even if it fails to produce one (for example a core run with no recovery). The activity type states whether the samples result from collection at a sampling feature, subsampling, aggregation of samples, or creation of a test or blank sample. Every sample refers to a sampling activity.</documentation> </annotation> </element>
