Schema documentation for component diggs:AggregateSlakeDurabilityTest

The procedure of a slake durability test. The slake durability index predicts the long-term durability of rock specimens, to establish the weathering and degradation characteristics of each rock type and to assess the impact of water on degradation.

<diggs:AggregateSlakeDurabilityTest gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:href="" nilReason="">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:testProcedureMethod xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureMethod>
  <diggs:testProcedureEquipment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testProcedureEquipment>
  <diggs:testingEnvironment xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:testingEnvironment>
  <diggs:otherTestProperty>{0,unbounded}</diggs:otherTestProperty>
  <diggs:testEvent>{0,1}</diggs:testEvent>
  <diggs:specimen xlink:href="" nilReason="" owns="false">{0,unbounded}</diggs:specimen>
  <diggs:drumMass howDetermined="" qualifier="" uom="">{0,1}</diggs:drumMass>
  <diggs:fragmentsRetainedDescription>{0,1}</diggs:fragmentsRetainedDescription>
  <diggs:fragmentsPassingDescription>{0,1}</diggs:fragmentsPassingDescription>
  <diggs:index1 howDetermined="" qualifier="" uom="">{0,1}</diggs:index1>
  <diggs:averageFluidTemperature howDetermined="" qualifier="" uom="">{0,1}</diggs:averageFluidTemperature>
  <diggs:maximumFluidTemperature howDetermined="" qualifier="" uom="">{0,1}</diggs:maximumFluidTemperature>
  <diggs:minimumFluidTemperature howDetermined="" qualifier="" uom="">{0,1}</diggs:minimumFluidTemperature>
  <diggs:slakingFluidDescription codeSpace="">{0,1}</diggs:slakingFluidDescription>
</diggs:AggregateSlakeDurabilityTest>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="AggregateSlakeDurabilityTest" type="diggs:AggregateSlakeDurabilityTestType" abstract="false" substitutionGroup="diggs:AbstractLaboratoryTestProcedure"> <annotation> <documentation>The procedure of a slake durability test. The slake durability index predicts the long-term durability of rock specimens, to establish the weathering and degradation characteristics of each rock type and to assess the impact of water on degradation.</documentation> </annotation> </element>
