Schema documentation for component diggs:Sample

A material sample, either solid, fluid, or gas that is obtained as a result of a sampling activity, for the purpose of observation and/or testing. This is a concrete representation of AbstractSample, which serves as the head of a substitution group for this and other sample specialties.

<diggs:Sample gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:projectRef xlink:actuate="" xlink:arcrole="" xlink:href="" identifierRef="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{1,1}</diggs:projectRef>
  <diggs:samplingActivityRef xlink:actuate="" xlink:arcrole="" xlink:href="" identifierRef="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{1,1}</diggs:samplingActivityRef>
  <diggs:sampleProducedRef xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{1,1}</diggs:sampleProducedRef>
  <diggs:relativeReferencingSystem>{0,1}</diggs:relativeReferencingSystem>
  <diggs:relativeReferenceSystemOrigin>{0,1}</diggs:relativeReferenceSystemOrigin>
  <diggs:classification>{0,1}</diggs:classification>
  <diggs:type codeSpace="">{0,1}</diggs:type>
  <diggs:condition codeSpace="">{0,1}</diggs:condition>
  <diggs:extrusionMethod codeSpace="">{0,1}</diggs:extrusionMethod>
  <diggs:initialContainer xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</diggs:initialContainer>
  <diggs:purpose>{0,1}</diggs:purpose>
  <diggs:sampleWeight howDetermined="" qualifier="" uom="">{0,1}</diggs:sampleWeight>
  <diggs:sampleVolume howDetermined="" qualifier="" uom="">{0,1}</diggs:sampleVolume>
  <diggs:sampleDimensions>{0,1}</diggs:sampleDimensions>
  <diggs:sampleMatrix codeSpace="">{0,1}</diggs:sampleMatrix>
  <diggs:initialPreservationMethod>{0,1}</diggs:initialPreservationMethod>
  <diggs:chainOfCustodyEvent xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:chainOfCustodyEvent>
  <diggs:otherSampleProperty>{0,unbounded}</diggs:otherSampleProperty>
  <diggs:coreDistkurbance codeSpace="">{0,1}</diggs:coreDistkurbance>
</diggs:Sample>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="false" name="Sample" substitutionGroup="diggs:AbstractSample" type="diggs:SampleType"> <annotation> <documentation>A material sample, either solid, fluid, or gas that is obtained as a result of a sampling activity, for the purpose of observation and/or testing. This is a concrete representation of AbstractSample, which serves as the head of a substitution group for this and other sample specialties.</documentation> </annotation> </element>
