Schema documentation for component diggs

An object that contains properties describing a water content test procedure. Water content or moisture content is the quantity of water contained in a material, expressed as a ratio. Also referred to as moisture content, this is the mass of water divided by the mass of the solids, expressed as a percentage.

<diggs_geo:WaterContentTest gml:id="" xmlns:diggs_geo="http://diggsml.org/schemas/3/geotechnical" xmlns:gml="http://www.opengis.net/gml/3.2" xmlns:diggs="http://diggsml.org/schemas/3">
  <gml:description xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:testProcedureMethod xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:testProcedureMethod>
  <diggs:testProcedureEquipment xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:testProcedureEquipment>
  <diggs:testingEnvironment>{0,unbounded}</diggs:testingEnvironment>
  <diggs:otherTestProperty>{0,unbounded}</diggs:otherTestProperty>
  <diggs:testEvent>{0,1}</diggs:testEvent>
  <diggs:specimen xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:specimen>
  <diggs_geo:waterContentDerivedFrom>{0,1}</diggs_geo:waterContentDerivedFrom>
  <diggs_geo:dryingTemperature howDetermined="" qualifier="" uom="">{0,1}</diggs_geo:dryingTemperature>
  <diggs_geo:dryingTime howDetermined="" qualifier="" uom="">{0,1}</diggs_geo:dryingTime>
  <diggs_geo:calciumCarbonateGasPressureMoistureReading howDetermined="" qualifier="" uom="">{0,1}</diggs_geo:calciumCarbonateGasPressureMoistureReading>
  <diggs_geo:heatingCycleParameters>{0,unbounded}</diggs_geo:heatingCycleParameters>
</diggs_geo:WaterContentTest>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="WaterContentTest" type="diggs_geo:WaterContentTestType" abstract="false" substitutionGroup="diggs:AbstractLaboratoryTestProcedure"> <annotation> <documentation>An object that contains properties describing a water content test procedure. Water content or moisture content is the quantity of water contained in a material, expressed as a ratio. Also referred to as moisture content, this is the mass of water divided by the mass of the solids, expressed as a percentage.</documentation> </annotation> </element>
