Schema documentation for component diggs:TriaxialTestEquipment

<diggs:TriaxialTestEquipment gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{0,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:class codeSpace="">{0,1}</diggs:class>
  <diggs:make>{0,1}</diggs:make>
  <diggs:modelNumber>{0,1}</diggs:modelNumber>
  <diggs:serialNumber>{0,1}</diggs:serialNumber>
  <diggs:calibrationAuditTrail>{0,unbounded}</diggs:calibrationAuditTrail>
  <diggs:otherEquipmentProperty>{0,unbounded}</diggs:otherEquipmentProperty>
  <diggs:loadCellCapacity howDetermined="" qualifier="" uom="">{0,1}</diggs:loadCellCapacity>
  <diggs:massOfTopPorousStone howDetermined="" qualifier="" uom="">{0,1}</diggs:massOfTopPorousStone>
  <diggs:massOfTopCap howDetermined="" qualifier="" uom="">{0,1}</diggs:massOfTopCap>
  <diggs:pistonDiameter howDetermined="" qualifier="" uom="">{0,1}</diggs:pistonDiameter>
  <diggs:poreWaterPressureDeviceMeetsUndrainedSpecs>{0,1}</diggs:poreWaterPressureDeviceMeetsUndrainedSpecs>
  <diggs:pressureTransducerType codeSpace="">{0,1}</diggs:pressureTransducerType>
</diggs:TriaxialTestEquipment>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element abstract="false" name="TriaxialTestEquipment" substitutionGroup="diggs:AbstractEquipment" type="diggs:TriaxialTestEquipmentType"> <annotation> <documentation>An object that contains properties to capture specific parameters of triaxial test proecdure equipment.</documentation> </annotation> </element>
