Complex Type diggs:EnergyPerVolumeMeasureType
Namespace http://diggsml.org/schemas/3
Annotations

Energy density or volumetric energy: Energy per unit volume. Used for fuel energy content, strain energy density, and compressed gas energy storage. Common units include J/m³, kJ/m³, MJ/m³, Btu/ft³, and kW·h/m³.
Diagram
DiagramEmlAllObjects_xsd_Simple_Type_eml_AbstractMeasure.tmp#AbstractMeasureMeasureTypes_xsd_Complex_Type_diggs_DescriptorValueType.tmp#DescriptorValueType_howDeterminedMeasureTypes_xsd_Complex_Type_diggs_DescriptorValueType.tmp#DescriptorValueType_qualifierMeasureTypes_xsd_Complex_Type_diggs_DescriptorValueType.tmp#DescriptorValueTypeMeasureTypes_xsd_Complex_Type_diggs_EnergyPerVolumeMeasureType.tmp#EnergyPerVolumeMeasureType_uom
Type extension of diggs:DescriptorValueType
Type hierarchy
Used by
Attributes
QName Type Use Annotation
howDetermined diggs:DescriptorMethodEnumType optional
qualifier diggs:QualifierEnumExtType optional
uom diggs:EnergyPerVolumeUomEnumType optional
The unit of measure for energy density or volumetric energy.
Source

<complexType name="EnergyPerVolumeMeasureType">
  <annotation>
    <documentation>Energy density or volumetric energy: Energy per unit volume. Used for fuel energy content, strain energy density, and compressed gas energy storage. Common units include J/m³, kJ/m³, MJ/m³, Btu/ft³, and kW·h/m³.</documentation>
  </annotation>
  <simpleContent>
    <extension base="diggs:DescriptorValueType">
      <attribute name="uom" type="diggs:EnergyPerVolumeUomEnumType">
        <annotation>
          <documentation>The unit of measure for energy density or volumetric energy.</documentation>
        </annotation>
      </attribute>
    </extension>
  </simpleContent>
</complexType>
Attribute diggs:EnergyPerVolumeMeasureType / @uom
Namespace No namespace
Annotations

The unit of measure for energy density or volumetric energy.
Type diggs:EnergyPerVolumeUomEnumType
Properties
content simple
Used by
Source

<attribute name="uom" type="diggs:EnergyPerVolumeUomEnumType">
  <annotation>
    <documentation>The unit of measure for energy density or volumetric energy.</documentation>
  </annotation>
</attribute>
