Schema documentation for component diggs:Project

A Project is a business activity that encompasses a collection of sampling features, activities, samples, observations and measurements. A project may occur at a physical location, in which case it can optionally contain geometries. A project is typically associated with an investigation or construction activity for which there a specific outcome anticipated - eg. a research publication, design, or an actual geotechnical construction (eg. deep foundation, earthwork, etc.)

<diggs:Project gml:id="" xmlns:diggs="http://diggsml.org/schemas/3" xmlns:gml="http://www.opengis.net/gml/3.2">
  <gml:description xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,1}</gml:description>
  <gml:identifier codeSpace="">{0,1}</gml:identifier>
  <gml:name codeSpace="">{1,unbounded}</gml:name>
  <diggs:internalIdentifier codeSpace="">{0,1}</diggs:internalIdentifier>
  <diggs:status codeSpace="">{0,1}</diggs:status>
  <diggs:implementationStatus codeSpace="">{0,1}</diggs:implementationStatus>
  <diggs:associatedFile xlink:actuate="" xlink:arcrole="" xlink:href="" nilReason="" owns="false" xlink:role="" xlink:show="" xlink:title="" xlink:type="simple">{0,unbounded}</diggs:associatedFile>
  <diggs:role>{0,unbounded}</diggs:role>
  <diggs:remark>{0,unbounded}</diggs:remark>
  <diggs:referencePoint xlink:role="" xlink:actuate="" xlink:show="" xlink:arcrole="" xlink:title="" xlink:href="" xlink:type="simple" nilReason="" owns="false">{0,1}</diggs:referencePoint>
  <diggs:linearExtent xlink:actuate="" xlink:role="" xlink:arcrole="" xlink:show="" xlink:title="" xlink:href="" xlink:type="simple" nilReason="" owns="false">{0,unbounded}</diggs:linearExtent>
  <diggs:arealExtent xlink:actuate="" xlink:role="" xlink:arcrole="" xlink:show="" xlink:title="" xlink:href="" xlink:type="simple" nilReason="" owns="false">{0,unbounded}</diggs:arealExtent>
  <diggs:projectDateTimeSpan>{0,1}</diggs:projectDateTimeSpan>
  <diggs:locality>{0,unbounded}</diggs:locality>
  <diggs:purpose codeSpace="">{0,1}</diggs:purpose>
  <diggs:projectEvent>{0,unbounded}</diggs:projectEvent>
  <diggs:contract>{0,unbounded}</diggs:contract>
  <diggs:otherProjectProperty>{0,unbounded}</diggs:otherProjectProperty>
</diggs:Project>

Database handle for the object. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. An external identifier for the object in the form of a URI may be constructed using standard XML and XPointer methods. This is done by concatenating the URI for the document, a fragment separator, and the value of the id attribute.

<element name="Project" type="diggs:ProjectType" substitutionGroup="diggs:AbstractProject" abstract="false"> <annotation> <documentation>A Project is a business activity that encompasses a collection of sampling features, activities, samples, observations and measurements. A project may occur at a physical location, in which case it can optionally contain geometries. A project is typically associated with an investigation or construction activity for which there a specific outcome anticipated - eg. a research publication, design, or an actual geotechnical construction (eg. deep foundation, earthwork, etc.)</documentation> </annotation> </element>
